| Facilities introduction |
To provide better services and products, it is important to have different measuring devices specific for evaluation. Here is the information of our evaluation machine.
|
|
Image Measuring Device Our measuring device can measure target size, Hole diameter, angle, hole pitch and level with one botton. It can measure 300 spots and 100 target at once. with the analyze function, it can lower the measurement error.
|
 |
coordinate measuring machine (cmm) It can measure surface dent and convex without mechanical contact. Main measurement: 3D image (surface irregularities), Cross-sectional shape, Ra, Sa. |
 |
Coordinate Measuring Machines It can measure height, length, hole diameter, surface roughness and R in 0.1μm automatically. Accretech Tokyo Seimitsu machine Measuring area：W850×D1000×H600 |
 |
Digital Mircoscope
It can provide quick and accurate measurement and simple picture in not just two dimensional but also in 3 dimensional. microscope maximum resolution: 5000x |
 |
CNC image measurement Contour measurement Size, Hoel diameter, Angle, Hole pitch, level difference, etc. It can measure automatically in μm. |
 |
Surface roughness mesurement
|
 |
Ceramic surface plate, squareness measurement It can measure by 1μm |
 |
Electric micrometer Comparision measurement. |
Check the facility introduction from here
Collaboration with KYOTO MUNICIPAL INSTITUTE OF INDUSTRIAL TECHNOLOGY AND CULTURE
Ceramic Parts Hong Kong is collaborating with Kyoto Municipal Institute of Industrial technology and culture(KITC)
Below systems are installed at KITC
- X-ray fluorescence
- Thermal analysis equipment
- Thermal conductivity measuring apparatus
- X-ray diffractometer
- Scanning electron microscopy
Joint research project is often held between KITC and Ceramic Parts Hong Kong to ensure product quality.
All Technical experiments are according to Hong Kong industrial Standard(JIS standard) as requested by Hong Kong Fine Ceramics Center(JFCC)
